YNXC-3000 automatic transformer degaussing machine is an equipment to eliminate residual magnetism after DC resistance test of large power transformers. It plays an extremely important role in protecting the transformer from the impact of magnetizing inrush current, putting it into operation safely and prolonging the life of the transformer.

1. It is suitable for removing residual magnetism before large power transformers of 35KV and above are put into operation.

2. The demagnetization speed is fast, and the three-phase transformer can be demagnetized once or twice.

3. The instrument is equipped with automatic test and manual test.

4. The degaussing current is 10A, and there are six degaussing currents of automatic, 10A, 5A, 1A, 500mA, and 200mA to meet the different test needs of users.

5. Use 220V AC power on site.

6. The progress percentage is displayed during the degaussing process.

7. The instrument is simple to operate, small in size, light in weight and easy to carry.

1. Main technical indicators:

Degaussing current: automatic, 10A, 5A, 1A, 500mA, 200mA in six gears.

Dimension: 400mm×310 mm×160 mm (length*width*height)

Weight: 6.5kg

2. Conditions of use

Ambient temperature: -10℃～50℃

Environmental humidity: ≤85%RH

Working power supply: AC220V±10%

Power frequency: 50±10 Hz
